| P2.5 led poster display parameters |
| Pixel structure | SMD 3 in one 2121 black leds with mask |
| Pixel launch | 2.5mm |
| Module Resolution | 64 * 64 |
| Module Size (mm) | 160W) * 160 (H) |
| Module Weight (kilograms) | 0.3 |
| Module Power Consumption (W) | 40 |
| Module Quantity | 2 (W) * 12 (H) |
| Display resolution | 256 (W) * 768 (H) |
| Frame size (mm) | 640 (W) * 2000 (H) * 100 (D) |
| Display area (m2) | 1.2288 |
| Cabinet (KG) | 45 |
| Pixel density (dots / pcs) | 196,608 |
| Brightness (CD) | 800 ~ 900 |
| Color temperature | 3200-9300, adjustable |
| Horizontal viewing angle (Deg) | 140 |
| Vertical viewing angle (Deg) | 120 |
| Deviation from the center distance of the light point | <3% |
| Brightness uniformity | > = 97% |
| Contrast ratio | 5000: 01: 00 |
| Maximum power consumption (W) | 650 |
| Average power consumption (W) | 220 |
| To scan | 1/32 |
| Frame change frequency (HZ) | 50-60 |
| Refresh rate (HZ) | 1920 |
| Lifetime (hours) | 100,000 |
| Working humidity (RH) | 10% ~ 80%, no condensation |
| Storage humidity (RH) | 40% ~ 60% |
