Fixed Installation LED Display Panel P10 Outdoor 960960mm Iron Cabinet Full Color Advertising LED Screen
Features:

    BLXTECH

    CHINA

    5-7 DAYS

    120 SQM/DAY

    Tentech’s P10 outdoor LED display panel, featuring a 960x960mm iron cabinet, is perfect for fixed installations. With full-color high-resolution visuals, it’s designed for impactful advertising. Durable, weatherproof, and energy-efficient, it ensures reliable performance in all conditions, making it ideal for outdoor digital signage and large-scale campaigns.
    1. Hight brightness.
    2. Full-color high-resolution visuals.
    3. Weatherproof and durable for outdoor use.
    4. Energy-efficient technology for cost savings.
    5. Long lifespan with minimal maintenance.


Fixed Installation LED Display Panel P10 Outdoor 960*960mm Iron Cabinet

BLXTECH ’s P10 Outdoor Fixed Installation LED Display Panel is a high-performance solution for outdoor advertising. Featuring a sturdy 960x960mm iron cabinet, it ensures durability, stability, and vibrant full-color visuals. Designed for fixed installations, it’s perfect for large-scale advertisements, stadiums, and public spaces, offering outstanding performance in all weather conditions.


Key Features:

P10 pixel pitch for sharp, detailed images.

Brightness up to 6,500 nits for visibility under sunlight.

Sturdy iron cabinet for enhanced durability.

IP65 waterproof and dustproof rating.

Wide viewing angles for maximum audience reach.

Easy front and rear maintenance.

Long lifespan with low power consumption.

Seamless modular design for scalability.

Supports multiple input formats.

Real-time monitoring for efficient operation.


Warrenty Terms - LED Display Screens

BLXTECH provides an excellent after-sales service on the prerequisite of customer satisfaction.

1. All the products owners purchased from BLXTECH possess the following rights:

A: Unconditional replacement within 7 days.

B: 2 years warranty for maintenance.

2. The repaired products will be sent back at BLXTECH cost to customer within 7 days( from the date we receive the defective products at customers cost).

3. 100% authentic strict assessment, for you to select high visibility, quality, good service goods; 10 times refund in case any fake were found.

4. 12 hours after-sale service BLXTECH professional services team promises to resolve any problems related to the use, installation and configuration of the product within 12 hours.

5. 30 days price protection If the price of the products as what you purchased is getting lower within 30 days, BLXTECH will refund the price difference.

Outdoor Fixed Install Specification

Module Specification

Model number3.076-134-10S5-8S6.67-6S8-5S10-4S
LED lampSMD1415SMD1921SMD3535
Pixel pitchP3.076P4P5P6.67P8P10
Module size320x160MM
Module resolution104 dots X 52 dots80 dots X 40 dots64 dots X 32 dots48 dots X 24 dots40 dots X 20 dots32 dots X 16 dots
Module thickness17MM
Brightness5000cd/㎡5500cd/㎡
Module weight0.46KG0.45KG0.45KG0.45KG0.44KG0.42KG

Cabinet Specification

Cabinet size (W/H)960mm X 960mm
Module quantity3pcs(W) x 6pcs(H) = 18 Pcs
Cabinet resolution312 dots X 312 dots240 dots X 240 dots192 dots X 192 dots144 dots X 144 dots120 dots X 120 dots96 dots X 96 dots
Cabinet Pixels97344 dots57600 dots36864 dots20736 dots14400 dots9216 dots
Pixel density105625 dots/㎡62500 dots/㎡40000 dots/㎡22500 dots/㎡15625 dots/㎡10000 dots/㎡
Service accessRear
Cabinet materialDie-casting Aluminum
Cabinet weight25Kg/pc

Screen Parameters

Brightness5000cd/㎡5500cd/㎡5500cd/㎡5500cd/㎡5500cd/㎡5500cd/㎡
Driving method1/13 Scan Constant Current1/10 Scan Constant Current1/8 Scan Constant Current1/6 Scan Constant Current1/5 Scan Constant Current1/4 Scan Constant Current
View angleHorizontal 140℃, Vertical 140℃
Best viewing distance3-10M4-12M5-15M6.5-20M8-24M10-30M
Brightness controlRed, Green and Blue 8192 Grade/Each
Refresh3840Hz
Input voltageAC: 110-240V  50~60Hz
Defects rate≤0.00001
Power consumptionMax.: 800W/㎡   Average: 300W/㎡
MTBF>10,000 Hours
Life span≥100,000 Hours
Brightness uniformity<0.01%
Earth leakage current<2mA
Protective gradeIP 66
Color281 Millions
OutputHDMI/DVI/VGA/RGB/PbPr (HDTV)
Operating temperature-20℃ to +60℃
Operating humidity10% to 90% RH
Controlling systemNovastar
Operating systemWindows10/me/2000/NT/XP/Windows7/Vistar
