LED Stadium Display, P3.076 P4 P5 P6.67 P8 P10 LED The Football Field Fence Display
Features:

    BLXTECH

    CHINA

    5-7 DAYS

    120 SQM/DAY

    Tentech’s Stadium LED Displays deliver exceptional visuals for live events, advertisements, and replays, ensuring an immersive audience experience. With high brightness, wide viewing angles, and a durable, weatherproof design, these displays are perfect for stadiums and arenas, offering reliable performance and easy maintenance in high-demand environments.
    Ultra-high brightness
    Wide viewing angles
    IP65-rated waterproof
    High refresh rate
    Easy to maintenance


Stadium LED Screens

BLXTECH ’s Stadium LED Screens provide unparalleled visual performance, perfect for live sports, advertisements, and event broadcasts. These high-quality displays are designed to enhance the audience experience with vibrant colors, clear visuals, and seamless operation. Built for durability and efficiency, they excel in large-scale, high-demand environments like stadiums and arenas.

Key Features:

1. Ultra-high brightness for clear daytime visibility.

2. Wide viewing angles for audience coverage.

3. IP65-rated waterproof and dustproof design.

4. Shock-resistant structure for safety in dynamic settings.

5. High refresh rate for smooth, flicker-free video.

6. Customizable sizes and configurations.

7. Energy-efficient operation for reduced costs.

8. Easy maintenance with modular components.

9. Real-time data and video input support.

10. Long lifespan with minimal degradation over time.




Warrenty Terms - LED Display Screens

BLXTECH provides an excellent after-sales service on the prerequisite of customer satisfaction.

1. All the products owners purchased from BLXTECH possess the following rights:

A: Unconditional replacement within 7 days.

B: 2 years warranty for maintenance.

2. The repaired products will be sent back at BLXTECH cost to customer within 7 days( from the date we receive the defective products at customers cost).

3. 100% authentic strict assessment, for you to select high visibility, quality, good service goods; 10 times refund in case any fake were found.

4. 12 hours after-sale service BLXTECH  professional services team promises to resolve any problems related to the use, installation and configuration of the product within 12 hours.

5. 30 days price protection If the price of the products as what you purchased is getting lower within 30 days, BLXTECH will refund the price difference.

Outdoor Fixed Install Specification

Module Specification

Model number3.076-134-10S5-8S6.67-6S8-5S10-4S
LED lampSMD1415SMD1921SMD3535
Pixel pitchP3.076P4P5P6.67P8P10
Module size320x160MM
Module resolution104 dots X 52 dots80 dots X 40 dots64 dots X 32 dots48 dots X 24 dots40 dots X 20 dots32 dots X 16 dots
Module thickness17MM
Brightness5000cd/㎡5500cd/㎡
Module weight0.46KG0.45KG0.45KG0.45KG0.44KG0.42KG

Cabinet Specification

Cabinet size (W/H)960mm X 960mm
Module quantity3pcs(W) x 6pcs(H) = 18 Pcs
Cabinet resolution312 dots X 312 dots240 dots X 240 dots192 dots X 192 dots144 dots X 144 dots120 dots X 120 dots96 dots X 96 dots
Cabinet Pixels97344 dots57600 dots36864 dots20736 dots14400 dots9216 dots
Pixel density105625 dots/㎡62500 dots/㎡40000 dots/㎡22500 dots/㎡15625 dots/㎡10000 dots/㎡
Service accessRear
Cabinet materialDie-casting Aluminum
Cabinet weight25Kg/pc

Screen Parameters

Brightness5000cd/㎡5500cd/㎡5500cd/㎡5500cd/㎡5500cd/㎡5500cd/㎡
Driving method1/13 Scan Constant Current1/10 Scan Constant Current1/8 Scan Constant Current1/6 Scan Constant Current1/5 Scan Constant Current1/4 Scan Constant Current
View angleHorizontal 140℃, Vertical 140℃
Best viewing distance3-10M4-12M5-15M6.5-20M8-24M10-30M
Brightness controlRed, Green and Blue 8192 Grade/Each
Refresh3840Hz
Input voltageAC: 110-240V  50~60Hz
Defects rate≤0.00001
Power consumptionMax.: 800W/㎡   Average: 300W/㎡
MTBF>10,000 Hours
Life span≥100,000 Hours
Brightness uniformity<0.01%
Earth leakage current<2mA
Protective gradeIP 66
Color281 Millions
OutputHDMI/DVI/VGA/RGB/PbPr (HDTV)
Operating temperature-20℃ to +60℃
Operating humidity10% to 90% RH
Controlling systemNovastar
Operating systemWindows10/me/2000/NT/XP/Windows7/Vistar
